Trelleborg Tires

Industrial Pneumatic Tire

The Trelleborg pneumatic tire range has been developed for heavy duty use on forklifts and other industrial vehicles. It offers customers an additional range of tires besides solid rubber and polyurethane products. All pneumatics have a lug type tread pattern providing optimal grip in every condition. The diagonal structure further insures high stability and maximum safety. The casing is of high tensile strength cord which offers good resistance to fatigue and improves comfort. The Trelleborg pneumatics are offered under the following product names:

Trelleborg TR-900 – Forklift Pneumatic Radial Tire

Trelleborg Wheel Systems Americas, Inc. has embarked on its newest journey; the arena of radial tires and the TR-900 tire line. This is the first offering of an industrial radial tire for Trelleborg. Featuring a complete size range that can stand up to even the toughest applications, the TR-900 is the all-around solution to your industrial tire needs. The TR-900 is available in the following sizes:

Description	Section Width (in) – inflated	Overall Diameter (in) – inflated	Tread Depth (in)-NSD	Inflation Pressure (PSI)	Load Capacity* (lbs)	Recommended Rim Size (in)	Weight (lbs)
6.00 R 9	6.4	21.3	29/32	145	3,190	4.00E	37.0
6.50 R 10	7.2	23.0	35/32	145	3,9660	5.00F	43.9
7.00 R 12	7.5	26.3	35/32	145	4,930	5.00S	59.0
7.00 R 15	7.6	28.9	35/32	145	5,500	5.50	69.5
28 x 9 R 15	8.7	27.8	29/32	145	7,100	7.00	74.7
2.50 R 15	9.9	28.9	32/32	145	8,000	7.00	77.0
7.50 R 15	8.3	30.3	38/32	145	6,600	6.00	84.2
8.25 R 15	9.4	32.9	40/32	145	8,040	6.50	105.0
3.00 R 15	12.3	32.8	45/32	145	11,350	8.00	135.5
10.00 R 20	11.5	41.7	42/32	145	11,680	8.00	200.6
12.00 R 20	12.5	44.7	51/32	145	15,650	8.50	253.5

*Load capacity for steer axle at 15 mph. With the perfect combination of industrial tire know-how and progressive radial technology, Trelleborg’s TR-900 Industrial Radial tire goes beyond traditional resilient and bias-ply pneumatic offerings. A tire that excels in stability, traction and ride quality, the TR-900 provides reduced fuel consumption with added security. With all of these advantages it’s no wonder the TR-900 is the most complete industrial radial tire on the market. Advantages of the Trelleborg TR-900 include:

• Longer tire life
• Better traction on all surfaces
• Low fuel consumption as a result of low rolling resistance
• Excellent ride quality
• Resistance to punctures
• Exceptionally high mileage performance
• Antistatic
